The Eva Scene Selector makes it easy to create the perfect ambiance in your smart home. It features two buttons for dimming and four buttons for different moods, such as "wake up," "night," "movie night," or any mood you desire.
Open the battery cover of the Eva Scene Selector by unscrewing the screw on the underside and sliding the cover downward.
Note: The LED will blink alternately between blue and red to indicate power-up and then display a pattern of 3 short blue blink every second to indicate pairing mode.
Close the cover on the scene selector by sliding it back into place and securing the screw on the underside of the scene selector.
Pairing the Eva Scene Selector to a hub/gateway
- Go into the Eva Smart Home app and add the Eva Scene Selector
- Scan the QR code to connect the scene selector to the Eva Hub.
- If the scene selector is not in pairing mode, you can also do the following: Press and hold buttons 1, 2, 3, and 4 simultaneously for more than 5 seconds to activate pairing mode. Pairing mode is indicated by the LED flashing 3 short blue flashes every second.
Press and hold buttons 1, 2, 3, and 4 for more than 5 seconds to reset and activate pairing mode.
Placement and Installation of the scene selector
For wall mounting, you can attach the mood switch with double-sided tape on the back of the wall bracket or secure the wall bracket with screws.
To attach the mood switch with screws, you can remove the back cover of the wall bracket and use the two screw holes on the back cover. You can also mount the mounting bracket in a standard-sized wall box. Choose the appropriate fastening method depending on the material the wall is made of. Screw the backplate to the wall bracket, attach the wall bracket to the backplate, and place the scene selector in the wall bracket.
Other Mounting Options
You can also remove the mood switch from the wall bracket and attach it to other magnetic surfaces since the mood switch has magnets on the inside.
|Blue||Repetitive: 3 short flashes, 1 second off||Pairing mode|
|Blue||1 second ON/OFF||Zigbee identification|
|Blue||Up to 10 medium flashes||Leave Network: The Scene Selector is removed from the Zigbee network|
|Blue||2 short flashes, 5 seconds off||Short poll|
|Red and blue||Flashes alternately||Startup|
|Red||Indicates button press|
Single button action
|Button 1||Short press||Activate scene configuration for button 1|
|Button 1||Press and hold for more then 10 seconds||Save scene on button 1|
|Button 2||Short press||Activate scene configuration for button 2|
|Button 2||Press and hold for more then 10 seconds||Save scene on button 2|
|Button 3||Short press||Activate scene configuration for button 3|
|Button 3||Press and hold for more then 10 seconds||Save scene on button 3|
|Button 4||Short press||Activate scene configuration for button 4|
|Button 4||Press and hold||Save scene on button 4|
|Button 5||Short press||Turn OFF dimming group|
|Button 5||Press and hold||Decrease brightness for dimming group|
|Button 6||Short press||Turn ON dimming group|
|Button 6||Press and hold||Increase brightness for dimming group|
|Button 1 and button 2||Press and hold at the same time||Light Linking group 1. Hold the mood switch until the device it is to be connected to.|
|Button 5 and button 6||Press and hold at the same time||Light Linking group 2. Hold the mood switch until the device it is to be connected to.|
|Button 3 and button 4||Press and hold simultaneously for more than 2 seconds||Synchronize dimming value on the dimming group (requires the device to be in a network)|
|Button 3 and button 5||Press and hold simultaneously for more than 2 seconds||Create group 1 (scenes) if identification is in progress. (Requires the device to be in a network)|
|Button 4 and button 6||Press and hold simultaneously for more than 2 seconds||Create group 2 (dimming) If identification is in progress. (Requires the device to be in a network)|
|Button 1 and button 5||Press and hold simultaneously for more than 2 seconds||Force short poll for 2 minutes (requires the device to be in a network)|
|Button 2 and button 6||Press and hold simultaneously for more than 5 seconds||Restart the device|
|Button 1 and button 6||Press and hold simultaneously for more than 5 seconds||Enable find and bind|
|Button 1 and button 2 and button 3 and button 4||Press and hold simultaneously for more than 5 seconds||Reset the device to factory settings followed by connection mode.|
|Button 3 and button 4 and button 5 and button 6||Press and hold simultaneously for more than 5 seconds||Resetting Light Link connections.|
Changing the batteries
(2 x CR2450 batteries)
- Open the battery cover on the Eva Scene Selector by unscrewing the screw on the underside and pushing the cover downwards.
- Remove and dispose of used batteries.
- Insert new batteries. The batteries should always be replaced in pairs with unused batteries.
- Slide the battery cover into place and screw in the screw.
Note: The LED will flash alternately between blue and red to indicate power-up, and will continue to flash red until the Scene Selector has connected to the Hub.
Important safety information
- For indoor use only
- Can be used in temperatures ranging from 0 ºC to 40 ºC.
- This product is not a toy, keep out of reach of children.
- Do not place near any heating source or in direct sunlight, as this may cause overheating.
- Only use correct type of batteries. Risk of fire or explosion, if the battery is replaced by an incorrect type.
- Do not use the equipment in case of any visible damage.
- Dispose of used batteries according to instructions.
For equipment including button and coin cells
- Do not ingest battery, Chemical Burn Hazard.
- If a coin or button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
- Keep new and used batteries away from children.
- If the battery compartment does not close securely, stop using the product and keep it away from children.
- If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.
Failure to observe recommendations included in this manual may be dangerous or cause a violation of the law. The manufacturer will not be held responsible for any loss or damage.
In the box
- Eva Scene Selector
- 2 x CR2450 batteries
- Stickers to the buttons
- Safety instructions
Information on disposal for users of waste electrical & electronic equipment
This symbol on the product and accompanying documents means that used electrical and electronic equipment (WEEE) should not be mixed with general household waste. For proper treatment, recovery and recycling, please take this product to designated collection points where it will be accepted free of charge. Alternatively, in some countries, you may be able to return your products to your local retailer upon purchase of an equivalent new product.
Disposing of this product correctly will help save valuable resources and prevent any potential negative effects on human health and the environment, which could otherwise arise from inappropriate waste handling. Please contact your local authority for further details of your nearest designated collection point. Penalties may be applicable for incorrect disposal of this waste, in accordance with your national legislation.
Software updates can be released by the manufacturer to fix bugs or enhance functionality after the product has been released. Updated software versions released will not impact continued compliance with applicable rules.
IP Class: IP 20 (indoor)
Radio protocol: Zigbee 3.0 & HA
Frequency: 2400-2483,5 MHz (IEEE 802.15.4)
Transmission power: 3dBm
Operating temperature: 0 to +40 °C
Storage temperature: -10 to +55 °C
Operating voltage: DC 3V
Declaration of Conformitty
Datek Smart Home AS declares that the equipment described in this document, is in compliance with the essential requirements and other relevant provisions of EU Directive 2014/53/EU. If you require a copy of the original signed DoC, please visit https://hjelp.evasmart.no/hc/no or scan QR code that can be found on the packaging of this product and select documents for your product.
Datek Smart Home AS
